Part No.: PCX-30-10
1. General Parameters
Lens Type: Plano-Convex (PCX)
Material: N-BK7 optical glass
Design Wavelength: 587 nm (d-line)
2. Geometric Specifications
Parameter: Value / Tolerance
Diameter: 30.0 mm / ±0.05 mm
Center Thickness: 10.0 mm / ±0.05 mm
Radius of Curvature*    : To be calculated / ±0.5%
*Note: Calculated via formula ( R = \frac{(n-1) \cdot CT}{1} ) (provide specific value upon request).
3. Optical Performance
Focal Length: Customizable (dependent on curvature)
Surface Quality: 40-20 scratch-dig per MIL-PRF-13830B
Surface Flatness: λ/4 @ 633 nm (plano surface)
4. Coating Options
Standard Coating: MgF₂ antireflective coating
Wavelength Range: 400–700 nm
Average Reflectance: <1.5% per surface
5. Mechanical & Environmental
Mounting Option: Unmounted (default) / Black anodized aluminum ring
Operating Temperature: -40°C to +80°C

Remarks:
Focal length and radius of curvature can be provided with exact refractive index data.
Custom specifications (e.g., UV/IR coatings, metrology reports) available upon request.
